Features
- Rubbered protection.
- Ribbed and sealed monobloc construction in aluminium alloy.
- Stainless steel rope.
- Adjustable capacity by means of a worm screw.
- Auxiliary safety suspension.
- Safety device against load dropping due to the spring breakage (>3kg).
- Centrifugal safety device.
- Upper rotary suspension with safety hook.
- Locking device to block the load at any height.
- Adjustable stroke limiting device.
- Taper drum rotating on ball bearings.
- Cable guide in antifriction material.
- Rotary upper hook with ball bearing.
- Inert spring drum assembly.
- Polyamides thimble.
Technical data
| ITEM | 9361G | 9362G | 9363G | 9364G | 9365G | 9366G | 9367G | 9368G | 9369G | |
| Capacity | kg | 10-15 | 15-20 | 20-25 | 25-30 | 30-35 | 35-45 | 45-55 | 55-65 | 65-75 |
| Stroke | mm | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 |
| Net weight | kg | 10.30 | 10.60 | 10.90 | 11.30 | 11.70 | 12.10 | 12.40 | 13.40 | 14.30 |
| Gross weight | kg | 11.8 | 12.1 | 12.4 | 13.3 | 13.3 | 14.1 | 14.1 | 15.0 | 15.8 |
| Package dimensions | mm | 590 265 260 |
590 265 260 |
590 265 260 |
590 265 260 |
590 265 260 |
590 265 260 |
590 265 260 |
590 265 260 |
590 265 260 |
