Features
- Rubbered protection.
- Ribbed and sealed monobloc construction in aluminium alloy.
- Stainless steel rope.
- Adjustable capacity by means of a worm screw.
- Auxiliary safety suspension.
- Safety device against load dropping due to the spring breakage (>3kg).
- Centrifugal safety device.
- Upper rotary suspension with safety hook.
- Locking device to block the load at any height.
- Adjustable stroke limiting device.
- Taper drum rotating on ball bearings.
- Cable guide in antifriction material.
- Rotary upper hook with ball bearing.
- Lining up upper hook.
- Visible cable for inspection.
- Inert spring drum assembly.
Technical Data
| ITEM | 9422G | 9423G | 9424G | 9425G | 9426G | |
| Capacity | kg | 100-120 | 120-140 | 130-150 | 140-160 | 160-180 |
| Stroke | mm | 2500 | 2500 | 2500 | 2500 | 2500 |
| Net weight | kg | 37.83 | 39.74 | 40.06 | 42.13 | 44.43 |
| Gross weight | kg | 40.0 | 41.9 | 42.2 | 44.3 | 46.6 |
| Package dimensions | mm | 670 300 360 |
670 300 360 |
670 300 360 |
670 300 360 |
670 300 360 |
