Axxair DC25-MS Orbital Facing Diameter ø3 - ø25.4mm
Orbital facing machine : portable, lightweight and designed to be used on site as well as in the workshop.
Tube facing consists in bringing the end of a tube or an accessory into conformity and acts on 3 aspects: the perpendicularity of the tube face (maintenance) - the surface state of the face - a length adjustment.
Burfree facing, the chip unrolls towards the outside of the tube, perfect preparation for thin tubes before orbital welding.
Technical Data
Burr-free tube squaring machine
Mains motor 1100 W
220-240 V ~50/60Hz or 120 V ~ 50/60Hz
Accurate manual advance, graduated vernier scale
Light and compact (2.5 kg)
Two speed gearbox with variable speed drive
High quality speed controller
Clamping shells : stainless steel jaws with spring
