EWM 090-002042-00502 Pico 162 MV 110/230V, 150Amps
- Inverter welding machine, DC, automatic mains voltage adaptation
- Welding procedures and functions
- MMA and Tig lift arc welding
- Arc-force, hot start, antistick
- Your benefits
- Portable, shoulder strap
- Overvoltage protection: No damage to machine caused if inadvertently connected to 400-V mains voltage
|
Version |
Input voltage: 230 V |
|
Input voltage: 115 V |
|
|
Setting range for welding current @ 230 V |
10 A - 150 A |
|
Setting range for welding current @ 115 V |
10 A - 110 A |
|
Duty cycle 40 °C @ 230 V |
150 A / 35 % |
|
120 A / 60 % |
|
|
100 A / 100 % |
|
|
Duty cycle 40 °C @ 115 V |
110 A / 35 % |
|
90 A / 60 % |
|
|
80 A / 100 % |
|
|
Open circuit voltage |
105 V |
|
Mains tolerances (ex works) @ 115 V |
up to |
|
Mains tolerances (ex works) @ 230 V |
up to |
|
Mains frequency |
50 Hz / 60 Hz |
|
Recommended generator power @ 230 V |
8.6 kVA |
|
Recommended generator power @ 115 V |
6.1 kVA |
|
Protection classification |
IP23 |
|
Test mark |
|
|
EMC class |
A |
|
Dimensions (L x B x H) |
361 mm x 136 mm x 224 mm |
|
361 mm x 136 mm x 224 mm |
|
|
Weight |
5.4 kg |
