Features
- Cools liquid TIG torches (L)
- Directly controlled by the power source via the power cable
- Features a water level safeguard to prevent low water levels
- Includes a water flow safeguard to prevent clogs
- Offers thermal protection to guard against abnormal heating
- Automatically detected by the generator
- Provides a dedicated purge function for the cooling unit or filling of bundles
Specifications
| Protection Level | IP23 |
| Dimensions (L x W x H) | 56 x 23 x 26 cm |
| Weight | 14 kg |
| EAN Code | 3154020070820 |
| Power Supply Voltage | 24V |
| Cooling Power at 1l/min at 25°C | 1 kW |
| Correction factor at 40°C | 0.58 |
| Maximum Pressure | 0.52 MPa (75 psi) |
| Tank Capacity | 3 L (0.66 gal US) |
| Functioning Temperature | -10°C to +40°C |
| Storage Temperature |
|
Compatible:
– TITANIUM 230 AC/DC FV (ref. 061996)
– TITAN 231 DC FV (ref. 075245)
– TITAN 321 DC TRI (ref. 068094)
