The BM20 Plus is a portable, heavy-duty edge preparation bevelling machine designed for bevelling both plate and pipes prior to welding with ease and accuracy, and is both operator-friendly and versatile. Its state-of-the-art electronic motor overload module offers additional protection to the machine and tooling. Equipped with a guide roller, the BM20 Plus is light and easy to operate.
Fitted with two rotary milling heads, each holding five 4-sided cutting inserts, the BM20 Plus allows for smooth operation and exceptional efficiency. An ideal beveller for edge preparation on plate as standard from 15 -60 degrees, up to a maximum bevel width of 21 mm. The BM20 Plus features a host of additional optional tooling that enhances the beveller's capabilities further for facing off steel, bevelling curved plate and pipe.
Specification
| Model | BM20 Plus |
| Motor | 1550/1600 W (for 50/60Hz, at 220 V) |
| 1700/1850 W (for 50/60Hz, at 110 V) / 1600 W (for 60Hz, at 110 V) | |
| Maximum Bevel Width | up to 20.5 mm (Bevelling at 30° and 60°) |
| up to 21 mm (Bevelling at 15° and 45°) | |
| Pipe Bevelling Dia. | 150 mm - 300 mm/ 260 mm - 600 mm (with additional attachments) |
| Motor Speed | 2780 - 3340 RPM (220 V) / 2740 - 3290 RPM (110 V) |
| Angle Range | 15-60° as Standard (0° Facing Off with additional attachment) |
| Tooling | Two Milling Heads with 10 square cutting inserts (4 sided) |
| Weight | 22 kg |
| Power Supply | 220 V/50Hz / 110 V / 60Hz |
