JEi SteelBeast 75FG SCANTOOL Floor belt grinder for industry
SCANTOOL 75FG floor belt grinders are the ideal grinders for large and heavy items that cannot be lifted/moved to the grinder. Used, among others in shipyards and in the wind mill industry for grinding of welds in floor height.
With SCANTOOL floor belt grinders the operator can stand up and grind in floor level. Operating handle is height adjustable and can customize any person. The pressure from the floor belt grinders are also adjustable and at the same time it is possible to adjust the belt grinding surface, so you can always use the full width of the grinding belt, although the floor is uneven. Ideal grinders for large and heavy items that cannot be lifted/moved to the grinder. Used, among others in shipyards and in the wind mill industry for grinding of welds in floor height. With SCANTOOL floor belt grinders the operator can stand up and grind in floor level. Operating handle is height adjustable and can customize any person.
The pressure from the floor belt grinders are also adjustable and at the same time it is possible to adjust the belt grinding surface, so you can always use the full width of the grinding belt, although the floor is uneven .
Specifications
| Model | SCANTOOL 75FG |
|---|---|
| Motor | 5.5 HP |
| RPM | 2800/3300 |
| Length / Width | 2000mm / 710mm |
| Grinding belt (mm) | 75x2000 |
| Height | 1000 |
| Net Weight | 70kg |
| Number of spindle speeds | 1 |
| Voltage / Part No. | 3x400/440V-50/60 Hz |
| Wheel size, Drive wheel (ø mm) | 200x75x28 |
| Wheel size, Contact wheel (ø mm) | 200x75x20 |
