Miller Syncrowave 300 AC/DC TIG Welder, 400V
For fabricators who need more TIG welding productivity and lower operating costs, Miller Syncrowave machines are the energy efficient TIG welding power sources that make it easier for any welder to get more work done.
Features
- Auto-Link circuit automatically links the power source to the primary voltage being applied (208/240/480 V, three - or single-phase).
- Simple & Easy to Install accept either single - or three-phase input power.
- Internal Cooler Power Supply runs the Coolmate S3 off the input power and requires no additional hook-up.
- Small footprint & Lightweight Design makes it easier to install and move around the workshop.
- Easy to Use intuitive user interface is simple to understand, making it easy to adjust parameters and thus, less time training new employees and more time getting the work done.
- Pro-Set Button gets to factory pre-set parameters with one touch of a button.
- Energy Efficient & Better Stability more stable arc and improved arc starts. Also, save up to 33% on energy costs against outdated welding equipment.
Specification
| Title | Syncrowave® 300 – TIG Runner |
| Industries Interests | Precision metal fabrication Maintenance and repair Light and heavy manufacturing Shipbuilding Tube and pipe Automotive |
| Material Thickness | |
| Weldable Metals | |
| Input Voltage | 380/400 V |
| Input Phase | 3-phase power |
| Input Hz | 50 Hz |
| Amperage Range | 5-300 A |
| Current Type | AC/DC |
| Rated Output | 300 A at 22 V, 30% duty cycle 210 A at 18 V, 60% duty cycle |
| Max Open Circuit Voltage | 60 VDC |
| Portability | |
| Weld Output | CC |
| Net Width | 521 mm (20.5 in.) |
| Net Height | 1114 mm (43.9 in.) |
| Net Length | 921 mm (36.3 in.) |
| Net Weight | 80 kg (176.4 lb.) |
| Warranty | 3 Years Miller’s True Blue Warranty |
