Miller 907858002 Dynasty® 400 AC/DC TIG Welding Machine (208V-600V)
Reimagined for Your Pursuit of Perfection. Experience unfailing precision arc performance paired with a state-of-the-art, user-friendly interface that puts advanced capabilities at your fingertips.
Features
- Portable in the shop or at the jobsite—at 6.0 kg (13.2 lb.) The shoulder strap allows the end user to move from location to location easily.
- Simple-to-use operator interface, inverter-based, DC power source has a simple-to-use operator interface providing only the necessary controls in a compact machine.
- Dual fan technology optimised power source cooling system which enables the machine to operate at a lower temperature, thus increasing its performance and life cycle.
- Thermal overload protection with an indicator light helps prevent machine damage if the duty cycle is exceeded or airflow is blocked.
- VRD function is a simple design that reduces the open-circuit voltage to 20 volts when the welding power source is not in use.
Specification
| Title | Dynasty® 400 |
| Industries Interests | Precision fabrication Heavy fabrication Pipe and tube fabrication Aerospace Aluminum ship repair Anodized aluminum fabrication |
| Material Thickness | |
| Weldable Metals | Thin to thick material. Steel, Stainless, Aluminium Special Alloys |
| Input Voltage | 208–600 V |
| Input Phase | 3-phase power or 1-phase power |
| Input Hz | 50/60 Hz |
| Amperage Range | 3–400 A |
| Current Type | AC/DC |
| Rated Output | 300 A at 32 V, 60% duty cycle |
| Max Open Circuit Voltage | 75 VDC |
| Portability | |
| Weld Output | CC |
| Net Width | 352 mm |
| Net Height | 613 mm |
| Net Length | 559 mm |
| Net Weight | 57 kg |
| Warranty | 3 Years Miller’s True Blue Warranty |
