Bohler Phoenix Spezial D (Basic Low Hydrogen) Mild Steel Electrodes
The Bohler Phoenix Spezial D is a premium double coated basic low hydrogen MMa stick electrodes designed for high quality mild steel welding. Classified under AWS A5.1 as E7016 and EN ISO 2560-A as E 42 3 B 12 H10, this electrode is highly regarded for its unique double-jacket coating. This design provides an incredibly stable, concentrated arc, making it highly effective for critical root passes, gap bridging, and demanding out-of-position fabrication.
Features
- Excellent weldability in all positions except vertical-down
- Well-controlled arc for out-of-position welding
- Excellent root penetration
- Easy to weld on AC
- Minimal spatter loss
- Low hydrogen content in the weld deposit
Technical Data
- AWS A5.1 / SFA-5.1: E7016
- EN ISO 2560-A: E 42 3 B 1 2 H10
- Carbon (C): 0.06%
- Silicon (Si): 0.65%
- Manganese (Mn): 1.05%
- Yield Strength (\(R_{eL}\) / \(R_{p0.2}\)): ≥ 420 MPa (Typical: 440 MPa)
- Tensile Strength (\(R_{m}\)): 500 – 640 MPa (Typical: 550 MPa)
- Elongation (A / L₀ = 5d₀): ≥ 20% (Typical: 28%)
