The NEOPULSE 320C is a digital 3 phase MIG/MAG pulse welding machine. It uses the latest technology to ensure the highest performance level. Digital interface is easy to use and practical, with a synergic mode which allows you to input details into your machine to ensure the perfect welding settings.
Features of GYS NEOPULSE 320C
- Multi-process welder – welds up to 1.2mm steel wire
- Synergic mode – Input the material/gas material and wire diameter and the machine will work out optimal welding conditions whilst still allowing you to adjust the settings
- Accurate calibration of the welding cables and motor speed, in order to adjust the voltage displayed and to refine the energy calculation
- 4 microprocessors designed for maximum productivity
- Designed for ease of use: New user friendly interface focused on welders navigation habits, update of the machine and synergies using a USB key, internal lighting of wire feed, viewing window on wire door to monitor level of wire.
- Storage of 500 welding programs
- Displays current/voltage before and after welding
Technical Data
- Input Voltage – 400V
- Amperage – 32A
- Duty Cycle @ 40C – 60% @ 300A 100% @ 280A
- Current Range – 10 – 320A
- No Load Voltage – 85V
- Wirefeed Motor – 4 Roll
- Wire Diameter – 0.6 – 1.2mm (Steel) 0.8mm-1.2mm (Aluminium)
- Weight – 36KG
- Warranty – 2 Years
- Package Includes – Machine only
- Wire Reel Capacity – 5KG, 15KG
